CONTREX M-Traverse - Manual (Page 104)

3 - 57
MV-57 DISCRETE OUTPUTS - GROUP B
The Discrete Outputs - Group B displays the status of the Output B discrete outputs.
The number “1” indicates an inactive or de-energized (logic high) level. The number “0”
indicates an active or energized (logic low) level. In the example below, “Output B” is
the inactive or de-energized (logic high) level.
Output B
Not Used
Not Used
Not Used
Not Used
Not Used
