APPENDIX B: FORMULAS
Use the following formulas to calculate Tach (MV-40)
and E.U. setpointing (MV-84, MV-86).
M-TRAVERSE FORMULAS
Tach and Engineering
Feedback
Velocity (RPMs) Feedback Frequency
(MV-42)
X 60
PPR Follower
(CP-18)
Follower
Profile
Length
(encoder lines)
Process
Ratio
Setpoint
(CP-01)
X Follower Lines/ E.U.
(CP-17)
E.U.
(CP-15)
Lead PPR Reel
(CP-16)
(MV-40)
(MV-86)
(MV-84)
Follower Lines/E.U.
(CP-17)
E.U.
(CP-15)
Traverse Length
(CP-02)
X
