2 - 22
Auxiliary DC Power (J3 pins 1, 2)
The 5 volt output (J3 pin 1) is a DC regulated output that can be used to power
encoders or other auxiliary equipment that is used in conjunction with the M–Traverse.
The 12 volt output (J3 pin 2) is a DC regulated output that can be used to power the
proximity sensors or other auxiliary equipment that is used in conjunction with the M–
Traverse. Refer to Figure 2-25.
WARNING
Do not exceed
the maximum current output of
250 mA for +5 VDC and
200 mA for +12 VDC.
Exceeding the maximum
current output
can damage the M–Traverse.
