50
Electrical connection
13. elecTrical cOnnecTiOn
13.1. safety instructions
DangEr!
risk of injury due to electrical shock!
• Before reaching into the device or the equipment, switch off the power supply and secure to prevent
reactivation!
• Observe applicable accident prevention and safety regulations for electrical equipment!
Warning!
risk of injury from improper installation!
• Installation may be carried out by authorized technicians only and with the appropriate tools!
risk of injury from unintentional activation of the system and an uncontrolled restart!
• Secure system from unintentional activation.
• Following installation, ensure a controlled restart.
13.2. electrical connection with circular plug-in
connector
if as-interface:
The designation of the circular plug-in connector and the contacts can be found in chapter “15.
AS-Interface”.
13.2.1. Designation of the circular plug-in connector
Functional earth FE
M12, 8-pole plug
Operating voltage
and diverse signals
1 2
3
4
5
6
7
8
Figure 25: Designation of the circular plug-in connector and contacts
english
Type 8791
