8630 - 83

PERATION

AND

ONTROLLER

UNCTIONS

➀

CAL.POS
Calibration of the position display (0 - 100 %)

Storage of the minimum position:

Move to minimum position via arrow keys and confirm by pressing the MANUAL / AUTOMATIC key.

Storage of the maximum position:

Move to maximum position via arrow keys and confirm by pressing the MANUAL / AUTOMATIC key.

➁

CAL INP
Calibration of the position setpoint (4 ... 20 mA; 0 ... 20 mA; 0 ... 5 V; 0 ... 10 V)

CAL SP
Calibration of the process setpoint (4 ... 20 mA; 0 ... 20 mA; 0 ... 5 V; 0 ... 10 V)

Menu point does not appear with selection of actual value frequency!

Storage of the minimum input signal (0 mA; 4 mA; 0 V):

Apply the minimum value of the standard signal to the input and confirm ist by pressing the MANUAL/
AUTOMATIC key.

Storage of the maximum input signal (20 mA; 5 V; 10 V):

Apply the maximum value of the standard signal to the input and confirm it by pressing the MANUAL/
AUTOMATIC key.

➂

CAL PV

Calibration of the process setpoint (4 ... 20 mA; Pt-100)

This menu item does not appear on selection of frequency setpoint

Select 4 ... 20 mA:

Apply the minimum value of the process setpoint signal to the input and confirm the value by pressing
the MANUAL/AUTOMATIC key.
Apply the maximum value of the process setpoint signal to the input and confirm the value by pressing
the MANUAL/AUTOMATIC key.

Select Pt-100:

Alter the value displayed using the arrow keys until thedisplay on the SIDE Control S/HART agrees with
that on the reference measuring instrument. Then confirm the value by pressing the MANUAL/
AUTOMATIC key.

NOTE

The signal types

shown in grey can be selected only with the process controller

activated.

The

signal surrounded by a dotted line can be selected only with the process

controller deactivated.

The

signal types in brackets are only shown in this menu; they cannot be

changed here. The type of signal shown is that which you have selected in the
associated menus:
CAL INP (CAL SP) Display of the selection in the menu INPUT
CAL PV Display of the selection in the menu P.CONTROL / P.CO INP

The

signal types over a grey background can be selected only with the option

flow rate controller.
