OPERATING CONDITIONS
Permissible ambient temperature - 10 ... + 50 °C
Protection type IP 65 to EN 60529 (only with correctly connected
cable or plug and socket)
CONFORMITY TO THE FOLLOWING STANDARDS
CE conformity wer. EMC Guideline 89/336/EWG
MECHANICAL DATA
Dimensions see data sheet
Housing material TOP Control outer: Noryl (PPE/PA), PSU, inner: PA 6
Dichtmaterial NBR
ELECTRICAL DATA
Connections Choice between multipole connector or
3 bushings M 16 x 1.5
with screw terminals 0.14 ... 1.5 mm²
Voltage supply 24 V DC ± 10 %
residual ripple 10 %
No industrial DC!
Power consumption < 5 W
Housing internal temperature
indication
- 55 ... + 125 °C, accuracy ± 2 °C
Input resistance for 180
Ω at 4 - 20 mA/resolution 12 bit
actual value signal 17 k Ω at frequency, 0 ... 1000 Hz / 1‰ of mean
> 300 V
ss
sinus, square-wave, sawtooth
PT-100 - 20 ... + 220 °C, resolution < 0.1 °C
Input resistance for 180
Ω at 0/4 - 20 mA/resolution 12 bit
setpoint signal 19 k Ω at 0 - 5/10 V /resolution 12 bit
Protection class 3 to VDE 0580
Analog position feedback:
max. current
for voltage output 0 ... 5/10 V 10 mA
max. burden
for current output 0/4 ... 20 mA 560
Ω
Inductive proximity switch
current limitation
100 mA
Data of the TOP Control Continuous
ATTENTION!
The TOP Control Continuous is not suitable for outdoor use.
