Extended System-Level Command Functions
76 Class Series 2 Programmer’s Manual
General Configuration Parameters – Identifier ‘G’
The ‘G’ sub-group contains network configuration parameters that apply ‘globally’ or
‘generally’ to any ethernet interface used. No sub-groups are currently defined for
the ‘G’ sub-group of configuration parameters, only item-value pairs. The ‘Item-
Value’ pairs within the ‘G’ sub-group are defined by the following table:
Item
Number
Name Available
to User
(Y/N)
Value Type Description
1 Primary Interface Y Decimal Indicates the primary or used
ethernet interface type. Interface
types are Wired Ethernet (802.3) and
Wireless Ethernet (802.11). It is
called ‘Primary’ since, in the future if
multiple ethernet interfaces would be
supported, it would be the PRIMARY
interface used.
2 Network Password Y String Provides the network password used
for WEB and TELNET sessions.
3 SNMP Enable Y Boolean Enables or Disables the SNMP
services.
4 Telnet Enable Y Boolean Enables or Disables the TELNET
services.
5 FTP Enable Y Boolean Enables or Disables the FTP Server.
6 HTTP Enable Y Boolean Enables or Disables the HTTP (WEB
Pages) Server.
7 LPD Enable Y Boolean Enables or Disables the LPD (Line
Printer Daemon) services.
8 NetBIOS Enable Y Boolean Enables or Disables the NetBIOS
services.
9 Netcenter Enable Y Boolean Enables or Disables the Netcenter
services.
10 Gratuitous ARP
Period
Y Decimal Value of the Gratuitous ARP Period in
seconds. 0 = Disabled.
11 Printer TCP Port Y Decimal Value of the TCP Port for Print
Services.
12 Default MTU N Decimal Provides a Default MTU Size (used
internally).
13 Static Primary WINS
Server IP Address Y String Static Primary WINS Server IP
Address in dotted decimal notation.
14 Static Secondary
WINS Server IP
Address
Y String Static Secondary WINS Server IP
Address in dotted decimal notation.
15 Static Primary DNS
Server IP Address Y String Static Primary DNS Server IP Address
in dotted decimal notation.
16 Static Secondary
DNS Server IP
Address
Y String Static Secondary DNS Server IP
Address in dotted decimal notation.
17 SNMP TRAP IP
Address Y String SNMP TRAP IP Address in dotted
decimal notation.
18 SNMP Server
Address
Y String SNMP Server IP Address in dotted
decimal notation.
19 NetBIOS Name Y String NetBIOS Name for the Printer.
20 Domain Name N String Domain Name – Not currently used.
21 Email Address N String Email Address – Not currently used.
