Extended System-Level Command Functions
Class Series 2 Programmer’s Manual 39
STX K}M Manual Media Calibration (Non-Display Models only)
This command causes the printer to save the sampled calibration values as an operator
places different portions of label stock within the media sensor. Depending upon the
printer model, different front panel LED flash sequences and printer responses (below)
will indicate calibration progress and outcome; see the corresponding printer operator
manual for LED flash sequences details. Sending to the printer instead of
will terminate the process and leave the TOF Sensor values unchanged.
Printer Response Alternate
LOAD STOCK[CR]
ENTER TO CONTINUE[CR]
N/A
LOAD MARK[CR]
ENTER TO CONTINUE[CR]
LOAD GAP[CR]
REMOVE STOCK[CR]
ENTER TO CONTINUE[CR]
N/A
PASSED CALIBRATION[CR] FAILED CALIBRATION[CR]
STX K}Q Quick Media Calibration (Non-Display Models only)
This command causes the printer to move media, sample, and then save sensor samples
as calibration values. This calibration function should be performed with media installed
in the printer. Depending upon the printer model, different front panel LED flash
sequences and printer responses (below) will indicate calibration progress and outcome;
see the corresponding printer operator manual for LED flash sequences details.
Printer Response Alternate
FAILED CALIBRATION[CR]
ADJUST GAIN SETTING[CR]
N/A
PASSED CALIBRATION[CR] FAILED CALIBRATION[CR]
