Appendix K –Maximum Row, Column, & Character Values; Print Resolutions & Widths; and, Module Identifiers & Allocations

272

Class Series 2 Programmer’s Manual

Print Resolutions and Maximum Width & Record Column Values

Model

Print Resolution

Dot Dimensions (nominal)

Maximum Print Width Maximum “gggg” Value

DPI

DPMM

Inches

Millimeters

Dots

Millimeters

Inch

Metric

A-4212

203

8.0

.0043 x .0052

.11 x .13

832

104.1

410

1041

A-4310

300

11.8

.0027 x .0043

.07 x .11

1248

105.7

416

1057

A-4408

406

16.0

.0013 x .0018

.03 x .05

1664

104.1

410

1041

A-4606

600

23.6

.0008 x .0015

.02 x .04

2496

105.7

416

1057

A-6212

203

8.0

.0043 x .0052

.11 x .13

1344

168.1

662

1680

A-6310

300

11.8

.0027 x .0043

.07 x .11

1920

162.6

640

1626

EX2

203

8.0

.0043 x .0052

.11 x .13

832

104.1

410

1041

E-4205e & E-Class

Mark III (203DPI)

203

8.0

.0043 x .0052

.11 x .13

864

108.0

425

1080

E-4304e & E-Class

Mark III (300DPI)

300

11.8

.0027 x .0043

.07 x .11

1248

105.7

416

1046

MP Compact MarkII

203

8.0

.0043 x .0052

.11 x .13

864

108.0

425

1080

MP Compact MarkII

300

11.8

.0027 x .0043

.07 x .11

1248

105.7

416

1046

H-4212 & H-4212X

203

8.0

.0043 x .0052

.11 x .13

832

104.1

410

1041

H-4310 & H-4310X

300

11.8

.0027 x .0043

.07 x .11

1248

105.7

416

1046

H-4408

406

16.0

.0013 x .0018

.03 x .05

1664

104.1

410

1041

H-4606 & H-4606X

600

23.6

.0008 x .0015

.02 x .04

2496

105.7

416

1057

H-6210 & H-6212X

203

8.0

.0043 x .0052

.11 x .13

1344

168.1

662

1680

H-6308 & H-6310X

300

11.8

.0027 x .0043

.07 x .11

1920

162.6

640

1626

H-8308X

300

11.8

.0027 x .0043

.07 x .11

2560

216.7

853

2167

I-4206, I-4208,

I-4210 & I-4212

203

8.0

.0043 x .0052

.11 x .13

832

104.1

410

1041

I-4308

300

11.8

.0027 x .0043

.07 x .11

1248

105.7

416

1046

I-4406

406

16.0

.0013 x .0018

.03 x .05

1664

104.1

410

1041

I-4604

600

23.6

.0008 x .0015

.02 x .04

2496

105.7

416

1057

M-Class 4206 &

4210 Mark II

203

8.0

.0043 x .0052

.11 x .13

864

108.0

425

1080

M-Class 4308 Mark II

300

11.8

.0027 x .0043

.07 x .11

1248

105.7

416

1046

Table K-2: Print Widths, Resolutions, and Record Column Field Values
