SIS Programming and Control, cont’d
IPI 100 and IPI 200 Series • SIS Programming and Control B-8
Command/response table for SIS commands
Command ASCII (Telnet)
(host to intercom)
URL Encoded
(host to intercom)
Response
(intercom to host)
Additional Description
Relay functions
Force relay on 1*1O 1 %2A1 O Rly 1 *1
] Turn relay on.
Force relay off 1*0O 1 %2A0 O Rly 1 *0
] Turn relay off.
Toggle relay 1*2O 1%2A2O Rly 1*
X%] Toggle relay on/off.
X%
= 1 (on) or 0 (off).
Pulse relay 1*3*
X6#
O 1%2A3%2A
X6#
O Rly 1 *
X%]
Rly 1 *
X%]
Set relay’s pulse time (
X6#
) in
20 ms increments from 1 (20 ms,
minimum) to 65535 (1310700 ms,
maximum).
Default pulse length is 25 = 500 ms.
N If the verbose mode is enabled, there are two responses from the unit because the relay is pulsed. During a pulse, the relay is
toggled to its opposite state and then back to the original state.
View the relay
state 1O 1O Rly 1 *
X%]
Front panel security lockout modes (executive modes)
Off 24 0X 0X Exe 0
] Executive mode is off.
On 24 1X 1X Exe 1
] Executive mode is on.
View lockout
mode status X X X20(] X20(
= Front panel lockout
(executive mode) status
0 = off/unlocked (default)
1 = on, disable/lock the front panel
Example: X X 0
] Executive mode is off.
Status commands
View all
voltage and
temperature
status 11S 11S shows responses to commands
12S•13S•14S•15S•16S•20S
]
View +12 V
P/S voltage 12S 12S +
X20^] X20^
= Voltage (in volts)
View +5 V IR
receiver port
voltage 13S 13S +
X20^]
View +3.3 V
IP Link/FPGA
voltage 14S 14S +
X20^]
View +1.5 V
FPGA voltage 15S 15S +
X20^]
View internal
temp. status 20S 20S X20&] X20&
=Temperature in degrees
Celsius (the response is 3 digits
including leading zeros)
