4-8 Using the Graphical “W ATER LOG” Software
DH-21
Box in upper right corner:
When there is a small box in the upper right corner, it is used to maximize the
window or display the window using the whole screen. Clicking on the box will
maximize it. If a window has been maximized, clicking on the box again will
return it to its normal size.
Box in upper left corner:
When there is a small box in the upper left corner, it is used to close the window.
Clicking on the box will close it.
Moving windows to different locations:
All of these windows may be moved by using the mouse to click on the window
name and dragging the window to the desired location.
Keyboard Options:
The keyboard can also be used to activate all functions within the program. When the
button has a label on it like “[O]peration Mode”, you can press a “O” or “o” on the
keyboard to select “Operation Mode”. The “TAB” key is used to jump between boxes and
the “OK”, “CANCEL”, “HELP” buttons. Within a box, the “ ” and “ ” keys are used to
highlight the selection wanted. Press the “SPACE” key to confirm your selection. Then
use the “TAB” key to highlight the “OK” button and press . The combination
of these keys will allow you to run the program without a mouse.
4.4 Main Options
4.4.1 Operation Mode
The Operation Mode has three options; Reset Sensor, Stop Logging and Start Logging.
4.4.1.1 Reset Option
Figure 4-2 shows a sample screen of when the “ W
ATER LOG” sensor is first installed. The first
option that you should invoke is “Operation Mode” Reset. Place the mouse cursor over the
“Operation Mode” button and press the left mouse button. Place the mouse cursor over the “( )”
in front of Reset Sensor and press the left mouse button. Then Click on the “OK” button to
continue the command. You will be notified that all data will be erased and the sensor will be
reset. Click on the “OK” button to acknowledge the message.
