3-14 Using the “W ATER LOG” Software
DH-21
As mentioned, this mode is used to simulate a logarithmic logging mode. Below is a simple
setup showing a logarithmic type logging setup.
Time Between Samples Number of Samples Time Interval
(Rate) (Samples)
Logging Rate 1 00:00:02 59 0 - 2 min.
Logging Rate 2 00:00:15 32 2 min. - 10 min.
Logging Rate 3 00:02:00 25 10 min. - 1 hr.
Logging Rate 4 00:15:00 28 1 hr. - 8 hrs.
Logging Rate 5 02:00:00 32 8 hrs. - 72 hrs.
Logging Rate 6 12:00:00 On going 72 hrs. -
This example shows the logging rate starting out fast and then slowing down. The rate can
change as needed; slow to fast, fast to slow and back to fast, etc.
The WaterLOG Serial # T2000 Version 1.1
Status = RESET (HYPER-DELTA) Last Measurement Units
Date/Time = 02/28/95 03:53:37
Date Started = 01/01/95 14:39:00 PRESSURE = 0.0000 PSI
Logging Rate = 00:01:00 TEMPERATURE = 0.00 Deg C
Next Log Time = 00:00:00
Memory Used = 0.0 %
Logging Count = 0 Scans
Battery = 6.8 Volts
1) Run 4) Time/Date 7) User Notes 10) Measure Data
2) Off 5) Logging Mode 8) Extract Data 11) Zero Sensor
3) Reset 6) Coefficients 9) View Data 12) Sensor Info
13) Diagnostics
Enter Option: 5 Esc-Exit
Variable Mode Rate Samples Rate Samples
1) 00:00:05 5 4) 00:01:00 0 7) Save/Exit
2) 00:00:30 5 5) 00:01:00 0
3) 00:01:00 0 6) 00:01:00 (Final Rate)
Enter Option: 7 Esc-Exit
Figure 3-9. Variable Logging Mode Option
