DH-21
Using the “W ATER LOG” Software 3-23
3.2.10 Measure Data Option
The Measure Data Option causes the “ W ATER LOG” to take a measurement as shown in Figure
3-20. The “ W
ATER LOG” makes the measurement and stores the results in the
FLASHEEPROM. The software in the computer will then query the “ W
ATER LOG” for the
measurement, which is displayed in the top right window of the screen.
The WaterLOG Serial # T2000 Version 1.1
Status = OFF (VARIABLE) Last Measurement Units
Date/Time = 02/28/95 04:11:27
Date Started = 02/28/95 04:00:00 PRESSURE = -0.0052 PSI
Logging Rate = 00:01:00 TEMPERATURE = 78.07 Deg F
Next Log Time = 04:07:55
Memory Used = 0.1 %
Logging Count = 15 Scans
Battery = 6.8 Volts
1) Run 4) Time/Date 7) User Notes 10) Measure Data
2) Off 5) Logging Mode 8) Extract Data 11) Zero Sensor
3) Reset 6) Coefficients 9) View Data 12) Sensor Info
13) Diagnostics
Enter Option: 10 Esc-Exit
Measure Data
Type any key to make a measurement.
(Data will be stored into Memory.)
Esc-Exit
Figure 3-20. Measure Data Option
3.2.11 Zero Sensor Option
The “ W
ATER LOG” software allows you to force the sensor to use a specific point as its zero
offset point. For example, placing the sensor in 5 feet of water and pressing option number 11
will cause the sensor to record levels with a -5.0 foot offset. Figure 3-21 shows the option
selected. Note: This option requires a “Y” or “N” conformation before it proceeds.
