Galaxy Vector Controller GCM2, GCM3
Appendix B - 4 T1.317 Objects and Attributes Issue 4 January 2008
Table B-9: Converter Plant
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
cp1,vdc Converter output voltage
√
number dd.d V
cp1,adc Converter load current
√
number dd.d A
cp1,vsp Converter float set-point
√ √
number 46-57:50V
cp1,dth Converter disconnect
threshold
√ √
number 20-26:21.00V
cp1,rth Converter reconnect threshold
√ √
number 22-26:22.20V
cp1,lvd Converter low voltage
disconnect √ √ number 0:disable 1:enable
Table B-10: Boost Management
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
bs1,bse Boost enable √ √ number 0:disable 1:enable
bs1,abe Auto boost enable √ √ number 0:disable 1:enable
bs1,amf Auto Boost multiplication
factor √ √ number 1-9
bs1,tmd Manual boost duration √ √ number 1-250:8 hours
Table B-11: Battery/Load Contactor
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
cn1,typ Contactor 1 type √ √ text "NONE","LOAD","BATTERY"
cn1,dth Low voltage disconnect
threshold
√ √
number 20-26:21V or 40-52:43.20V
cn1,rth Low voltage reconnect
threshold
√ √
number 20-26:22.20V or 40-52:44.40V
cn2,typ Contactor 2 type
√ √
text "NONE","LOAD","BATTERY"
cn2,dth Low voltage disconnect
threshold √ √ number 20-26:21V or 40-52:43.20V
cn2,rth Low voltage reconnect
threshold √ √ number 20-26:22.20V or 40-52:44.40V
