Galaxy Vector Controller GCM2, GCM3
4 - 8 Installation and Configuration Issue 4 January 2008
Table 4-A: Configuration Parameters
Main Menu
Heading
Parameter
Description
Range
(24V, 48V Systems)
Default (24V, 48V Systems)
Standard Flexent
Float Voltage
System float
voltage set point
22-28V, 44-56V 27.24V, 54.48V 27.24V, 54.48V
High float voltage
major alarm
25-30V, 50-60V 28.24V, 57V 28.5V, 57.0V
High float voltage
minor alarm
25-30V, 50-60V 27.74V, 56V 27.74, 56.0V
Battery discharge
major alarm
23-27.5V, 46-55V 25.54V, 51.1V 25.0V, 51.1V
Very low voltage
major alarm
20-25.5V, 40-51V 23.00V, 46.00V 23.0V, 46.0V
Rectifiers
Rectifier output
float current limit
30-110% 100% 110%
Number of
rectifiers on line
1-24 24, 1 24
Shunts
System shunt type Battery, load, none Battery Battery
Shunt 1 current
rating
0-9999A 800A 1000A
Shunt 2 current
rating
0-9999A 0A 0A
