Galaxy Vector Controller GCM2, GCM3
Appendix B - 2 T1.317 Objects and Attributes Issue 4 January 2008
Table B-1: Power System
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
ps1,des Power system description
√
text "Tyco Vector Controller"
ps1,sid Site ID
√ √
text Up to 15 characters:""
ps1,swv Software version
√
text Vector software version
ps1,usl Update serial link
& clear alarms
√ √
number 1
Table B-2: DC Plant
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
dc1,stt Plant state √ √ text "FLOAT", "BOOST"
dc1,vdc Plant voltage √ number dd.dd V
dc1,adc Plant load current
√
number dddd A
dc1,sht Plant shunt type
√ √
text "NONE","LOAD","BATTERY"
dc1,sha1 Plant shunt 1 size
√ √
Number 0-9999:800 0 means none
dc1,sha2 Plant shunt 2 size √ √ Number 0-9999 0 means none
dc1,trd Plant Total Rectifier Drain √ number dddd A
Table B-3: Alarm Thresholds
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
hva1,fth Very High Float Voltage Major √ √ number 25-30:28.24V or 50-60:57V
hva1,bth Very High Boost Voltage Major √ √ number 26-30:28.24V or 52-60:57V
hfv1,fth High Float Voltage Minor √ √ number 25-30:27.74V or 50-60:56V
hfv1,bth High Boost Voltage Minor
√ √
number 25-30:27.74V or 50-60:56.20V
bda1,thr Battery on Discharge
√ √
number 23-27.50:25.54V or 46-55:51.10V
vla1,thr Very Low Voltage
√ √
number 20-25.5:23V or 40-51:46V
bta1,thr Battery Thermal Alarm
√ √
number 30:85:55°C
Table B-4: Rectifier Management
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
gm1,fsp Rectifier float set-point
√ √
number 22-28.5:27.24V or 44-56:54.48V
gm1,bsp Rectifier boost set-point
√ √
number 24-30:27.24V or 48-60:55.20V
gm1,fcl Rectifier float current limit
√ √
number 30-110:100%
gm1,bcl Rectifier boost current limit √ √ number 30-110:100%
gm1,rone Rectifiers on while on engine √ √ number 1-24
