Galaxy Vector Controller GCM2, GCM3
Issue 4 January 2008 Installation and Configuration 4 - 11
Battery Discharge
Test Results
After initiating a Battery Discharge Test through the Operations
menu, the user obtains the data or results from a battery
discharge test through the View Status menus. Selecting
Battteries
> Battery Test Result displays the result of the last
battery test. The Vector stores the result of the last completed
test. This is the recorded data (not manually changeable) for the
battery test result. Refer to the battery discharge test operation
for detail test procedure and results.
Pressing the Battery Test Result softkey displays an indication
of the last battery test performed. The display indicates either
that the test was completed or not completed. In addition, the last
completed battery test results are saved and can be accessed by
pressing the “
< View Completed” softkey. This allows the user
to observe the reserve time and load current during the test. If for
some reason the test was completed and results were
unsatisfactory, the message “Check Battery” is displayed. If the
last test was interrupted, the message “Not Available” is
displayed. If a test was stopped before completion, the phrase
“Previous Test Was Interrupted” will also appear when the
Battery Test softkey is pressed.
Communication
ports
Local port baud rate
setting
Auto/1200 to 19,200 Auto Auto
Local port flow
control setting
None/SW/HW None None
Modem port baud
rate setting
Auto/1200 to 19,200 2400 2400
Modem port flow
control setting
None/SW/HW None None
Number of rings
before modem
answers
1 to 9 1 1
Calibrate to meter
Calibrate system
voltage to a new
value
22-28V, 44-56V System voltage N/A
Calibrate converter
voltage to a new
value
46-57V Converter voltage N/A
Table 4-A: Configuration Parameters (Continued)
Main Menu
Heading
Parameter
Description
Range
(24V, 48V Systems)
Default (24V, 48V Systems)
Standard Flexent
