Galaxy Vector Controller GCM2, GCM3
Issue 4 January 2008 Troubleshooting 5 - 1
5 Troubleshooting
Replacing Circuit
Packs
Table 5-A lists the circuit packs available as replacements in the
Vector Controller.
Table 5-A: Replacement Circuit Packs and Temperature Modules
Designation Description
Ordering
Number
210E Thermal Probe Multiplexer 107789513
BLJ3 Connection Board 848262622
BMW2 VC Control Panel 108358102
BSM3 Modem Board 108415647
BSM4 Local Port Isolation Board 848501037
BTJ2 +24V Outdoor Connection Board 108629528
BTJ3 -48V Outdoor Connection Board 108963562
EBW1 Gateway Network Card 108340100
GCM2 24V Vector Control Board 108890088
GCM3 48V Vector Control Board 108890096
-- LCD Display Module 848518577
-- Keypad 848569430
BMW2, LCD, Keypad Entire Display Assembly 848597563
Checking the
highest battery
temperature
If temperature probes are connected to the controller and thermal
compensation is enabled, the highest battery temperature can be
calculated based on the plant voltage. Temperatures between the
battery thermal lower temperature and the battery thermal
nominal temperature can be calculated if the raising of system
voltage is also enabled.
Calculate the temperature as follows:
voltage difference
= (system set point – system voltage reading)
cells per string
where cells per string is the number of 2-volt cells per string.
