Galaxy Vector Controller GCM2, GCM3
Issue 4 January 2008 Product Description 2 - 13
Control Signal Inputs
Table 2-K: BLJ3 Control Signal Inputs
Control Signal
Name
Description Indoor Input Connection
RO Reserve Operation closure to BAT
PBT Power Battery Test closure to BAT
BLJ3 Power
Connections Power connections from the system to the BLJ3 (factory wired).
Table 2-L: Power Connections BLJ3
Description
Input
Termination
Associated
Fuse
Plant Termination
(+) PWR Controller BAT F2 Charge Bus (Rectifier bus)
(-) PWR Controller DG Discharge Return Bus
LVD power #1 See note 1 NA Charge Bus (Rectifier bus)
LVD power #2 See note 1 NA Battery Bus
Aux. Bat. Source
ABS
See note 2
F1 NA
Note 1: LVD control power, from the power buses for the indoor system, is connected to the
BJNx LVD controller board
Note 2: BLJ3 user available fused (F1) power terminations are labeled ABS. DG terminations are
also provided for user termination on the BLJ3. These terminations are labeled DG.
