Galaxy Vector Controller GCM2, GCM3
Appendix A - 6 Communications Issue 4 January 2008
• Always consider personal safety. Be aware of the presence of
battery potential in the vicinity of the controller.
• Use only insulated tools.
Verify that no controller related alarms are active on the LCD
display panel. If controller alarm is active, consult the “Galaxy
Vector Controller ACP-BIC2, BIC3” or the “Galaxy Vector
Controller GCM2, GCM3” product manual for troubleshooting
help.
Tools/Equipment
Required
Before installing and configuring the Galaxy Gateway, the
following tools/equipment are required:
• Flat jeweler’s screwdriver (controller DIP switch setting)
• Small Phillips head screwdriver
• Nut driver for 6-32 nut
• PC with terminal emulation program (example:
HyperTerminal)
• 9 pin male serial interface cable (DB-9 male) to connect to
Galaxy Gateway
• Network interface cable (CAT 5 UTP)
Unpacking the
Galaxy Gateway
The 108876400 Galaxy Gateway Kit has been inspected, tested
and carefully packed. Examine the shipping carton and all
components for any sign of shipping damage.
1. Check for external damage to the shipping cartons.
2. Remove all parts from shipping cartons.
3. Check the following table and verify that all components
are present.
