Galaxy Vector Controller GCM2, GCM3
Issue 4 January 2008 Installation and Configuration 4 - 9
Batteries
Type Valve-regulated, flooded Valve-regulated Valve-regulated
Battery discharge
test enable
Enabled/Disabled Disabled Disabled
High battery
temperature major
alarm
30° to 85°C 55°C 75°C
Battery temperature
compensation
enable
Enabled/Disabled Disabled Enabled
High battery
temperature
stepdown voltage
45° to 85°C 75°C 75°C
High battery
temperature voltage
decrease stop
(upper slope limit)
30° to 55°C 45°C 53°C
High battery
temperature voltage
decrease rate (upper
slope per cell)
1 to 5mV/°C 3mV 3mV
Nominal
temperature (no
voltage
compensation)
15° to 30°C 25°C 25°C
Battery low
temperature
compensation
voltage increase
enable
Enabled/Disabled Disabled Disabled
Low battery
temperature voltage
decrease stop
(lower slope limit)
-5° to 20°C 0°C -5°C
Low battery
temperature voltage
decrease rate (lower
slope per cell)
1 to 5mV/°C 3mV 3mV
Battery recharge
current limit enable
Enabled/Disabled Disabled Disabled
Battery recharge
current limit
threshold
10-1000A 1000A 1000A
Table 4-A: Configuration Parameters (Continued)
Main Menu
Heading
Parameter
Description
Range
(24V, 48V Systems)
Default (24V, 48V Systems)
Standard Flexent
