Galaxy Vector Controller GCM2, GCM3
4 - 10 Installation and Configuration Issue 4 January 2008
Contactors
Contactor 1 type Battery/Load/None None Battery
Disconnect voltage,
contactor 1
20-26V, 40-52V 21V, 43.2V 21.25, 43.2V
Reconnect voltage,
contactor 1
20-26V, 40-52V 22.2V, 44.4V 25.00, 44.4V
Contactor 2 type Battery/Load/None None N/A, None
Disconnect voltage,
contactor 2
20-26V, 40-52V 21V, 43.2V N/A, 43.2V
Reconnect voltage,
contactor 2
20-26V, 40-52V 22.2V, 44.4V N/A, 44.4V
Converters
Converter set point
voltage
46-57V 50V N/A
Converter
shutdown voltage
(disconnect
threshold)
20-26V 21V N/A
Converter
shutdown voltage
enable (low voltage
disconnect)
Enable/Disable Disable N/A
Converter restart
voltage (reconnect
threshold)
20-26V 22.2V N/A
Boost
Boost feature
enable
Enable/Disable Disable Disable
Boost set point
system voltage
24-30V, 48-60V 27.24V, 55.2V N/A, 55.2V
High boost voltage
major alarm
threshold
26-30V, 52-60V 28.24V, 57V N/A, 57.0V
High boost voltage
minor alarm
threshold
25-30V, 50-60V 27.74V, 56.2V N/A, 56.2V
Auto boost feature
enable
Enable/Disable Disable Disable
Auto boost duration
(_ × BD duration)
1 to 9 1 N/A, 1
Manual boost
duration
1-250 hours 8 N/A, 8
Boost current limit
(rectifier limit
during boost)
30%-110% 100% N/A, 100%
Table 4-A: Configuration Parameters (Continued)
Main Menu
Heading
Parameter
Description
Range
(24V, 48V Systems)
Default (24V, 48V Systems)
Standard Flexent
