Galaxy Vector Controller GCM2, GCM3
Issue 4 January 2008 T1.317 Objects and Attributes Appendix B - 3
Table B-5: Rectifiers (xx is 01 to 24)
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
gxx,stt Individual rectifier state
√ √
text "ON","OFF","STANDBY",
"VACANT"
gxx,adc Individual rectifier current √ number ddd
Table B-6: Battery Reserve Management
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
br1,cle Batt recharge current limit
enable
√ √
number 0:disable 1:enable
br1,clt Battery recharge current limit
√ √
number 10-1000 A
br1,btc Battery test class
√ √
text "FLOODED","VALVE-REG"
br1,bte Battery test enable √ √ number 0:disable 1:enable
br1,btr Battery test results √ mixed result, reserve, load
code: ok, aborted, failed, not run,
interrupted
reserve: dd.d (hours)
load: dddd (amps)
br1,bts Battery test state
√ √
number 0:inactive 1:active
Table B-7: Battery Sections
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
b01,adc Battery section 1 current
√
dddd A
b02,adc Battery section 2 current
√
dddd A
Table B-8: Controller Battery Temperature Channels
Related Commands
OBJ,ATTR DESCRIPTION STA CHA OPE TYPE RANGE OF VALUES
ct1,val Controller battery temp chan 1
√
dd °C
ct2,val Controller battery temp chan 2
√
dd °C
ct3,val Controller battery temp chan 3
√
dd °C
ct4,val Controller battery temp chan 4
√
dd °C
