DS2153Q
022697 31/48
DS2153Q JITTER TOLERANCE Figure 12–2
MINIMUM TOLERANCE
LEVEL AS PER
ITU G.823
DS2153Q
TOLERANCE
10 100 1K 10K 100K 1
1K
100
10
1
0.1
1.5
0.2
40
20 2.4K 18K
FREQUENCY (Hz)
UNIT
INTER
V
ALS (Ulpp)
DS2153Q TRANSMIT WAVEFORM TEMPLATE Figure 12–3
269 ns
G.703
TEMPLATE
194 ns
219 ns
–250 –200 –150 –100 –50 0 50 100 150 200 250
1.2
1.1
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
–0.1
–0.2
SCALED AMPLITUDE
(in 75 ohm systems, 1.0 on the scale=2.37Vpeak in 120 ohm systems, 1.0 on the scale=3.00Vpeak)
TIME (ns)
