DS2153Q
022697 26/48
RAF: RECEIVE ALIGN FRAME REGISTER (Address=2F Hex)
(MSB)
(LSB)
Si
0
0
1
1
0
1
1
SYMBOL
POSITION
NAME AND DESCRIPTION
Si
RAF.7
International Bit.
0
RAF.6
Frame Alignment Signal Bit.
0
RAF.5
Frame Alignment Signal Bit.
1
RAF.4
Frame Alignment Signal Bit.
1
RAF.3
Frame Alignment Signal Bit.
0
RAF.2
Frame Alignment Signal Bit.
1
RAF.1
Frame Alignment Signal Bit.
1
RAF.0
Frame Alignment Signal Bit.
RNAF: RECEIVE NON–ALIGN FRAME REGISTER (Address=1F Hex)
(MSB)
(LSB)
Si
1
A
Sa4
Sa5
Sa6
Sa7
Sa8
SYMBOL
POSITION
NAME AND DESCRIPTION
Si
RNAF.7
International Bit.
1
RNAF.6
Frame Non–Alignment Signal Bit.
A
RNAF.5
Remote Alarm.
Sa4
RNAF.4
Additional Bit 4.
Sa5
RNAF.3
Additional Bit 5.
Sa6
RNAF.2
Additional Bit 6.
Sa7
RNAF.1
Additional Bit 7.
Sa8
RNAF.0
Additional Bit 8.
TAF: TRANSMIT ALIGN FRAME REGISTER (Address=20 Hex)
(MSB)
(LSB)
Si
0
0
1
1
0
1
1
SYMBOL
POSITION
NAME AND DESCRIPTION
Si
TAF.7
International Bit.
0
TAF.6
Frame Alignment Signal Bit.
0
TAF.5
Frame Alignment Signal Bit.
1
TAF.4
Frame Alignment Signal Bit.
