16. Parts List
PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series
97
9' Diameter 60° Hopper Bin Specifications Parts List
Ref #
Part #
Description
Qty
1
BLK-12266
9' 30° Roof Panel (20 Gauge) (Shown)
9
1
BLK-12269
9' 40° Roof Panel (20 Gauge)
9
2
9' Sidewall Sheet
3 Per Ring
2
SS40682009
20 Gauge (Top Punched Sidewall Sheet)
2
SS41662009
20 Gauge (Top Punched Decal Sidewall Sheet)
2
SS40692009
20 Gauge (Middle Punched Sidewall Sheet)
2
SS40691809
18 Gauge (Middle Punched Sidewall Sheet)
2
SS40691709
17 Gauge (Middle Punched Sidewall Sheet)
2
SS40701509
15 Gauge (Middle Leg Punched Sidewall Sheet)
2
SS40712009
20 Gauge (Bottom Leg Punched Sidewall Sheet)
2
SS40711809
18 Gauge (Bottom Leg Punched Sidewall Sheet)
2
SS40711709
17 Gauge (Bottom Leg Punched Sidewall Sheet)
2
SS40711509
15 Gauge (Bottom Leg Punched Sidewall Sheet)
3
BLK-12311
9' 60° Offset Hopper Panel 16" Opening (18 Gauge) (Shown)
9
3
BLK-12313
9' 60° Hopper Panel 22" Opening (18 Gauge)
9
4
BLK-12036
9' Leg 140-1/2" (12 Gauge) (2-5 Rings) (Shown)
6
4
BLK-12037
9' Leg 164-1/2" (10 Gauge) (6 Rings)
6
5
BLK-12109
Hopper Brace for 16" Collar (Shown)
6
5
BLK-12110
Hopper Brace for 22" Collar
6
6
BLK-12342
16" 60° Hopper Collar (18 Holes) (Shown)
1
6
BLK-10342
22" 60° Hopper Collar (36 Holes)
1
7
BLK-12058
9' Inside Cross Tie Brace (67.788") (12 Gauge)
6
7
BLK-12059
9' Outside Cross Tie Brace (67.788") (12 Gauge)
6
8
BLK-11730
30° Bulk Tank Peak Ring (Shown)
1
8
BLK-12534
40° Bulk Tank Peak Ring
1
9
BLK-12730
9' 60° Hopper Reinforcement Angle (3-6 Ring Tanks Only)
9
