16. Parts List
PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series
89
7' Diameter 67° Hopper Bin Specifications Parts List
Ref #
Part #
Description
Qty
1
BLK-12260
7' 30° Roof Panel (20 Gauge) (Shown)
6
1
BLK-12263
7' 40° Roof Panel (20 Gauge)
6
2
7' Sidewall Sheet
2 Per Ring
2
SS40602007
20 Gauge (Bottom/Top Leg Punched Sidewall Sheet)
2
SS41642007
20 Gauge (Bottom/Top Leg Punched Decal Sidewall Sheet)
2
SS40612007
20 Gauge (Top Punched Sidewall Sheet)
2
SS41652007
20 Gauge (Top Punched Decal Sidewall Sheet)
2
SS40462007
20 Gauge (Middle Punched Sidewall Sheet)
2
SS40461807
18 Gauge (Middle Punched Sidewall Sheet)
2
SS40461707
17 Gauge (Middle Punched Sidewall Sheet)
2
SS40641707
17 Gauge (Middle Leg Punched Sidewall Sheet)
2
SS40641507
15 Gauge (Middle Leg Punched Sidewall Sheet)
2
SS40661807
18 Gauge (Bottom Leg Punched Sidewall Sheet)
2
SS40661707
17 Gauge (Bottom Leg Punched Sidewall Sheet)
2
SS40661507
15 Gauge (Bottom Leg Punched Sidewall Sheet)
3
BLK-11476
7' 67° Offset Hopper Panel 16" Opening (18 Gauge) (Shown)
6
3
BLK-10569
7' 67° Hopper Panel 22" Opening (18 Gauge)
6
4
BLK-12039
7' Leg 140-1/2" (12 Gauge) (1-4 Rings) (Shown)
4
4
BLK-12040
7' Leg 164-1/2" (10 Gauge) (5-6 Rings)
4
5
BLK-12107
Hopper Brace for 16" Collar (Shown)
4
5
BLK-12108
Hopper Brace for 22" Collar
4
6
BLK-10488
16" 67° Hopper Collar (Shown)
1
6
BLK-10341
22" 67° Hopper Collar (36 Holes)
1
7
BLK-12056
7' Inside Cross Tie Brace (72.49") (12 Gauge)
4
7
BLK-12057
7' Outside Cross Tie Brace (72.49") (12 Gauge)
4
8
BLK-11730
30° Bulk Tank Peak Ring (Shown)
1
8
BLK-12534
40° Bulk Tank Peak Ring
1
9
BLK-12009
7' 67° Hopper Reinforcement Angle (5-6 Ring Tanks Only)
6
