16. Parts List
96 PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series
9' Diameter 60° Hopper Bin Specifications
IMPORTANT: Bolt heads are inside of bin at the Leg to Body attachment and on all vertical seams on
hopper panels. All bolts to be tightened from the nut side only. Refer to detail on Page 22
for location of caulking.
Under Collar Clearance
16" Collar 28-1/16" (713 mm)
22" Collar 32-5/8" (829 mm)
