PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series 21
6. Sidewall Assembly
Tank Sidewalls
Sidewall Sheet Gauge Chart
How to use charts on this page:
The chart labeled “Sidewall Sheet Gauge Chart” is for the reference when building the tank. This chart tells
you what gauges your rings of the specific tank must have. To read the chart find the tank size you are
build. For example, a 7' diameter tank with 4 rings is referred to as BFT 7'-4 ring. The side labeled “Gauge”
will indicate which sidewall sheets to use. The sheets are color coded, simply match the gauge number
with the color. (Use “Sheet Gauge Color Code Chart”
below .)
NOTE: Sidewall sheets are color coded on edges for gauge identification.
Sheet Gauge Color Code Chart
Model Gauge
BFT 6'-1 Ring 20
BFT 6'-2 Ring 20-20
BFT 6'-3 Ring 18-20-20
BFT 6'-4 Ring 18-20-20-20
BFT 7'-1 Ring 20
BFT 7'-2 Ring 18-20
BFT 7'-3 Ring 18-20-20
BFT 7'-4 Ring 18-18-20-20
BFT 7'-5 Ring 17-17-18-20-20
BFT 7'-6 Ring 15-15-17-18-20-20
BFT 9'-1 Ring 20
BFT 9'-2 Ring 20-20
BFT 9'-3 Ring 20-20-20
BFT 9'-4 Ring 18-18-20-20
BFT 9'-5 Ring 17-17-18-20-20
BFT 9'-6 Ring 15-15-17-18-20-20
Code # Color Code
20 Red
18 Orange
17 Pink/Light Blue
16 Blue
15 Brown/Red
14 Green
13 Yellow/Blue
12 Black
11 Pink
10 Light Blue
