16. Parts List
PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series 87
* NOTE: Bolt listed first and nut second for each usage.
Hardware usage: Heads of bolts are on the outside of tank unless otherwise noted.
6' Diameter 60° Hopper Bin Hardware Specifications Parts List
Ref # Part # Description Qty
1 S-10260
Bulk Tank Peak Ring to Roof Panels (Use 5/16" x 1" Hex Head Bin Bolts and
5/16" Hex Nuts.)
36
1 S-7484 36
2 S-10260
Roof Panel to Roof Panel (Use 5/16" x 1" Hex Head Bin Bolts and 5/16" Hex Nuts.)
48
2 S-7484 48
3 S-10260
Roof Panels to Top Sidewall Sheets (Use 5/16" x 1" Hex Head Bin Bolts and
5/16" Hex Nuts.)
72
3 S-7484 72
4 S-10260
Vertical Sidewall Sheet Seams (Use 5/16" x 1" Hex Head Bin Bolts and
5/16" Hex Nuts.)
Varies
4 S-7484 Varies
5 S-10260
Horizontal Sidewall Sheet Seams (Use 5/16" x 1" Hex Head Bin Bolts and
5/16" Hex Nuts.)
Varies
5 S-7484 Varies
6 S-10260
Leg to Sidewall Sheet (Use 5/16" x 1" Hex Head Bin Bolts and 5/16" Hex Nuts.)
(Bolt Heads to Inside of Tank.)
48
6 S-7484 48
7 S-10260 Hopper Panels to Sidewall Sheet (Use 5/16" x 1" Hex Head Bin Bolts
and 5/16" Hex Nuts.) (Bolt Head to Inside at Leg to Hopper to Sidewall
Connection Only.) 72
7 S-7484 72
8 S-10267
Vertical Hopper Seams (Use 5/16" x 3/4" Truss Head Bin Bolts and 5/16"
Flanged Whiz Nuts.) (Bolt Heads to Inside of Tank.)
108
8 S-10268 108
9 S-10267
Hopper Collar to Hopper Panel (Use 5/16" x 3/4" Truss Head Bin Bolts and 5/16"
Flanged Whiz Nuts.) (Bolt Heads to Inside of Tank.) (16" Shown.)
24 or 36
9 S-10268 24 or 36
10 S-7485
Hopper Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.)
4
10 S-7489 4
Ref # Description Ref # Description
A Inside G Leg
B Outside H Offset Hopper Panel
C Roof Sheet I Hopper Sheet
D Body Sheet J Hopper Collar
E Peak Ring Collar K Hopper Brace
F Hopper Panel
