13. Legs and Leg Bracing
PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series 71
Extra Clearance Leg Adjustment
In cases where extra clearance is required (on 7' 67° and 9' 60° tanks only), you may raise the tank up to
8" when installing the legs.
See Figure 13G for proper positioning. Call company’s engineering for any
other special requirements.
* NOTE: If 7'-4 ring and 9'-4 ring 60° tanks are raised, they will require a safety cage ladder package.
2 Ring Leg 164-1/2" (4178 mm)
* NOTE: 9'-5 Ring tanks must utilize 2 ring coverage legs if raising 8" (203.2 mm).
Figure 13G Leg Adjustment (7' (5-6 Ring) 67° and 9' (6 Ring) 60° Only)
Failure to follow instructions may cause damage or failure of the equipment.
WARNING
22 Holes 19 Holes
