10. Safety Cage
52 PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series
Safety Cage Installation
Vertical Supports
After all three (3) hoop assemblies are in place, attach the 48" vertical supports from hoop assembly to
hoop assembly as shown in
Figure 10F . This requires fourteen (14) supports, seven (7) between each set
of hoops. The second set of vertical supports must be bent at the flat area to allow for the tapering of the
bottom hoop assembly. Use 5/16" x 1" bolts with the head of the bolt to the inside of the safety cage.
Figure 10F
Ref # Part # Description
A LS-6713 Safety Cage 48" Vertical Supports
