16. Parts List

100

PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series

9' Diameter 45° Hopper Bin Specifications

IMPORTANT: Bolt heads are inside of bin at the leg to body attachment and on all vertical seams on

hopper panels. All bolts to be tightened from the nut side only. Refer to detail

for location of caulking. No cross tie bracing required.

Under Collar Clearance

16" Collar

30-11/16" (779 mm)

22" Collar

33-1/4" (844 mm)
