16. Parts List
PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series
91
* NOTE: Bolt listed first and nut second for each usage.
Hardware usage: Heads of bolts are on the outside of tank unless otherwise noted.
7' Diameter 67° Hopper Bin Hardware Specifications Parts List
Ref #
Part #
Description
Qty
1
S-10260
Bulk Tank Peak Ring to Roof Panels (Use 5/16" x 1" Hex Head Bin Bolts and
5/16" Hex Nuts.)
36
1
S-7484
36
2
S-10260
Roof Panel to Roof Panel (Use 5/16" x 1" Hex Head Bin Bolts and 5/16" Hex Nuts.)
60
2
S-7484
60
3
S-10260
Roof Panels to Top Sidewall Sheets (Use 5/16" x 1" Hex Head Bin Bolts and
5/16" Hex Nuts.)
84
3
S-7484
84
4
S-10260
Vertical Sidewall Sheet Seams (Use 5/16" x 1" Hex Head Bin Bolts and
5/16" Hex Nuts.)
Varies
4
S-7484
Varies
5
S-10260
Horizontal Sidewall Sheet Seams (Use 5/16" x 1" Hex Head Bin Bolts and
5/16" Hex Nuts.)
Varies
5
S-7484
Varies
6
S-10260
Leg to Sidewall Sheet (Use 5/16" x 1" Hex Head Bin Bolts and 5/16" Hex Nuts.)
(Bolt Heads to Inside of Tank.)
52 or 88
6
S-7484
52 or 88
7
S-10260
Hopper Panels to Sidewall Sheet (Use 5/16" x 1" Hex Head Bin Bolts
and 5/16" Hex Nuts.) (Bolt Head to Inside at Leg to Hopper to Sidewall
Connection Only.)
84
7
S-7484
84
8
S-10267
Vertical Hopper Seams (Use 5/16" x 3/4" Truss Head Bin Bolts and 5/16"
Flanged Whiz Nuts.) (Bolt Heads to Inside of Tank.)
162
8
S-10268
162
9
S-10267
Hopper Collar to Hopper Panel (Use 5/16" x 3/4" Truss Head Bin Bolts and 5/16"
Flanged Whiz Nuts.) (Bolt Heads to Inside of Tank.) (16" Shown.)
24 or 36
9
S-10268
24 or 36
10
S-7485
Hopper Brace to Leg (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.)
4
10
S-7489
4
11
S-7485
Cross Tie Brace (Use 3/8" x 1" Flange Head Bolts and 3/8" Hex Nuts.)
12
11
S-7489
12
Ref #
Description
Ref #
Description
A
Inside
G
Leg
B
Outside
H
Hopper Reinforcement Angle (5-6 Rings Only)
C
Roof Sheet
I
Leg Cross Tie
D
Body Sheet
J
Offset Hopper Panel
E
Peak Ring Collar
K
Hopper Collar
F
Hopper Panel
L
Hopper Brace
