8. Optional BFT Ladder Assembly
34 PNEG-1460 6', 7' and 9' Bulk Feed Tank BFT Series and GHT Series
Roof Ladder Support Bracket Installation (Continued)
Figure 8F Figure 8G
Ref # Part # Description
A LDR-4198 Wedge
B S-3550 5/16" x 1" Carriage Bolt
C
LDR-5403 30° Support Bracket
LDR-5404 40° Support Bracket
D S-10268 Flange Nut 5/16"-18 JS Grade 5
E Ladder
