BluStar Device Status
6-5 41-001391-00 Rev 03 – 04.2012
Advanced LDAP Settings
When configuring an LDAP directory the option is available to customize the directory using the advanced parameters
listed below. These advanced parameters are available for both active and non-active directories.
Note:
Advanced LDAP settings are optional and are not required for configuring the BluStar 8000i to use a LDAP server for
reading directories over an IP network.
Parameter Description
LDAP name title attribute list Specifies the LDAP name title (e.g. Mr.) for the attribute list. If this parameter contains more than one value, only
the first matching value will be selected in the record.
For example, Setting_LDAP name title attribute list=title
LDAP first name attribute list Specifies the LDAP first name (e.g. John) for the attribute list. If this parameter contains more than one value,
only the first matching value will be selected in the record.
For example, Setting_LDAP first name attribute list=fname
LDAP last name attribute list Specifies the LDAP last name (e.g. Doe) for the attribute list. If this parameter contains more than one value,
only the first matching value will be selected in the record.
For example, Setting_LDAP last name attribute list=name
LDAP middle name attribute list Specifies the LDAP middle name (e.g. Allen) for the attribute list. If this parameter contains more than one
value, only the first matching value will be selected in the record.
For example, Setting_LDAP middle name attribute list=mname
LDAP name suffix attribute Specifies the LDAP name suffix (e.g. Ph.D) for the attribute list. If this parameter contains more than one value,
only the first matching value will be picked in the record.
For example, Setting_LDAP name suffix attribute=suffix
LDAP company attribute list Specifies the LDAP company name (e.g. Aastra) for the attribute list. If this parameter contains more than one
value, only the first matching value will be selected in the record.
For example, Setting_LDAP company attribute list=organization
LDAP job title attribute list Specifies the LDAP job title (e.g. Vice President) for the attribute list. If this parameter contains more than one
value, only the first matching value will be selected in the record.
For example, Setting_LDAP job title attribute list=jtitle
LDAP business street attribute list Specifies the LDAP business street (e.g. Snow Blvd.) for the attribute list. If this parameter contains more than
one value, only the first matching value will be selected in the record.
For example, Setting_LDAP business street attribute list=waddress
LDAP business city attribute list Specifies the LDAP business city (e.g. Concord) for the attribute list. If this parameter contains more than one
value, only the first matching value will be selected in the record.
For example, Setting_LDAP business city attribute list=wcity
LDAP business state attribute list Specifies the LDAP business state (e.g. Ontario) for the attribute list. If this parameter contains more than one
value, only the first matching value will be selected in the record.
For example, Setting_LDAP business state attribute list= wstate
LDAP business postal code attribute
list Specifies the LDAP business postal code (e.g. L4K 4N9) for the attribute list. If this parameter contains more than
one value, only the first matching value will be selected in the record.
For example, Setting_LDAP business postal code attribute list=bcode
LDAP business country attribute list Specifies the LDAP business country (e.g. Canada) for the attribute list. If this parameter contains more than one
value, only the first matching value will be selected in the record.
For example, Setting_LDAP business country attribute list=bcountry
LDAP home street attribute list Specifies the LDAP home street (e.g. Internet Blvd.) for the attribute list. If this parameter contains more than
one value, only the first matching value will be selected in the record.
For example, Setting_LDAP home street attribute list=hstreet
LDAP home city attribute list Specifies the LDAP home city (e.g. Frisco) for the attribute list. If this parameter contains more than one value,
only the first matching value will be selected in the record.
For example, Setting_LDAP home city attribute list=hcity
LDAP home state attribute list Specifies the LDAP home state (e.g. Texas) for the attribute list. If this parameter contains more than one value,
only the first matching value will be selected in the record.
For example, Setting_LDAP home state attribute list=hstate
