Prestige 2602HW Series User’s Guide
Chapter 3 Wizard Setup 73
3.2.7 DHCP Setup
DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows individual
clients to obtain TCP/IP configuration from a server. You can configure the Prestige as a
DHCP server or disable it. When configured as a server, the Prestige provides the TCP/IP
configuration for the clients. If you turn DHCP service off, you must have another DHCP
server on your LAN, or else the computer must be manually configured.
3.2.7.1 IP Pool Setup
The Prestige is pre-configured with a pool of 32 IP addresses starting from 192.168.1.33 to
192.168.1.64 for the client machines. This leaves 31 IP addresses, 192.168.1.2 to
192.168.1.32 (excluding the Prestige itself which has a default IP of 192.168.1.1) for other
server machines, for example, server for mail, FTP, telnet, web, etc., that you may have.
3.2.8 Internet Access Wizard Setup: Fourth Screen
Verify the settings in the screen shown next. To change the LAN information on the Prestige,
click Change LAN Configurations. Otherwise click Save Settings to save the configuration
and skip to the section 3.13.
Authentication
Password
Type the password associated with the user name above. You can use up to
95 ASCII Extended set characters.
Send Caller ID Select this check box to show identification information when you make VoIP
phone calls. Clear the check box to not show identification information when
you make VoIP phone calls.
Back Click Back to go back to the previous screen.
Next Click Next to continue to the next wizard screen.
Table 9 Internet Access Wizard Setup: Voice Configuration (continued)
LABEL DESCRIPTION
