Prestige 2602HW Series User’s Guide
Chapter 21 Maintenance 259
21.5 Wireless Screen
The read-only screen displays information about the Prestige’s wireless LAN.
21.5.1 Association List
This screen displays the MAC address(es) of the wireless stations that are currently logged in
to the network. Click Wireless LAN and then Association List to open the screen shown next.
Figure 121 Association List
The following table describes the fields in this screen.
MAC Address This field displays the MAC (Media Access Control) address of the computer with the
displayed IP address.
Every Ethernet device has a unique MAC address. The MAC address is assigned at
the factory and consists of six pairs of hexadecimal characters, for example,
00:A0:C5:00:00:02.
Refresh Click Refresh to update this screen.
Table 80 Any IP Table
LABEL DESCRIPTION
Table 81 Association List
LABEL DESCRIPTION
# This is the index number of an associated wireless station.
MAC Address This field displays the MAC (Media Access Control) address of an associated wireless
station.
Every Ethernet device has a unique MAC address. The MAC address is assigned at
the factory and consists of six pairs of hexadecimal characters, for example,
00:A0:C5:00:00:02.
Association
Time
This field displays the time a wireless station is associated to the Prestige.
Back Click Back to return to the previous screen.
Refresh Click Refresh to renew the information in the table.
