Prestige 2602HW Series User’s Guide

404

Chapter 42 VPN/IPSec Setup

Figure 258 Menu 27 VPN/IPSec Setup

42.2 IPSec Summary Screen

Type 1 in menu 27 and then press [ENTER] to display Menu 27.1 IPSec Summary. This is a
summary read-only menu of your IPSec rules (tunnels). Edit or create an IPSec rule by
selecting an index number and then configuring the associated submenus.

Figure 259 Menu 27.1 IPSec Summary

Menu 27 - VPN/IPSec Setup

1. IPSec Summary
2. SA Monitor

Enter Menu Selection Number:

Menu 27.1 – IPSec Summary

#

Name

A

Local Addr Start

- Addr End / Mask Encap

IPSec Algorithm

Key Mgt

Remote Addr Start

- Addr End / Mask

Secure GW Addr

-

------

-

-----------------

---------------

------

------------------

001

Taiwan

Y

192.168.1.35

192.168.1.38

Tunnel

ESP AES MD5

IKE

172.16.2.40

172.16.2.46

193.81.13.2

002

zw50

N

1.1.1.1

1.1.1.1

Tunnel

AH SHA1

IKE

4.4.4.4

255.255.0.0

zw50test.zyxel.

003

China

N

192.168.1.40

192.168.1.42

Tunnel

ESP DES MD5

IKE

N/A

N/A

0.0.0.0

004

005

Select Command= None

Select Rule= N/A

Press ENTER to Confirm or ESC to Cancel:

Table 133 Menu 27.1 IPSec Summary

FIELD

DESCRIPTION

#

This is the VPN policy index number.

Name

This field displays the unique identification name for this VPN rule. The name may be up

to 32 characters long but only 10 characters will be displayed here.
