Prestige 2602HW Series User’s Guide

466

The following are Internal SPTGEN screens associated with the SMT screens of your Prestige.

PVA

Parameter Values Allowed

INPUT

An example of what you may enter

*

Applies to the Prestige.

Table 165 Abbreviations Used in the Example Internal SPTGEN Screens Table

ABBREVIATION

MEANING

Table 166 Menu 1 General Setup (SMT Menu 1)

/ Menu 1 General Setup (SMT Menu 1)

FIN

FN

PVA

INPUT

10000000 =

Configured

<0(No) | 1(Yes)>

= 0

10000001 =

System Name

= Prestige

10000002 =

Location

=

10000003 =

Contact Person's Name

=

10000004 =

Route IP

<0(No) | 1(Yes)>

= 1

10000006 =

Bridge

<0(No) | 1(Yes)>

= 0

Table 167 Menu 3 (SMT Menu 3 )

/ Menu 3.1 General Ethernet Setup (SMT menu 3.1)

FIN

FN

PVA

INPUT

30100001 =

Input Protocol filters Set 1

= 2

30100002 =

Input Protocol filters Set 2

= 256

30100003 =

Input Protocol filters Set 3

= 256

30100004 =

Input Protocol filters Set 4

= 256

30100005 =

Input device filters Set 1

= 256

30100006 =

Input device filters Set 2

= 256

30100007 =

Input device filters Set 3

= 256

30100008 =

Input device filters Set 4

= 256

30100009 =

Output protocol filters Set 1

= 256

30100010 =

Output protocol filters Set 2

= 256

30100011 =

Output protocol filters Set 3

= 256

30100012 =

Output protocol filters Set 4

= 256

30100013 =

Output device filters Set 1

= 256

30100014 =

Output device filters Set 2

= 256

30100015 =

Output device filters Set 3

= 256

30100016 =

Output device filters Set 4

= 256

/ Menu 3.2 TCP/IP and DHCP Ethernet Setup (SMT Menu 3.2)
