Prestige 2602HW Series User’s Guide

356

Chapter 36 System Information and Diagnosis

The following table describes the fields present in Menu 24.1 — System Maintenance —
Status which are read-only and meant for diagnostic purposes.

Figure 210 Menu 24.1 System Maintenance : Status

The following table describes the fields present in Menu 24.1 — System Maintenance —
Status.

Menu 24.1 - System Maintenance - Status 00:36:37

Sat. Jan. 01, 2000
Node-Lnk Status TxPkts RxPkts Errors Tx B/s Rx B/s Up
Time
1-PPPoA N/A 0 0 0 0 0 0:00:00
2 N/A 0 0 0 0 0 0:00:00
3 N/A 0 0 0 0 0 0:00:00
4 N/A 0 0 0 0 0 0:00:00
5 N/A 0 0 0 0 0 0:00:00
6 N/A 0 0 0 0 0 0:00:00
7 N/A 0 0 0 0 0 0:00:00
My WAN IP (from ISP): 0.0.0.0
Ethernet: WAN:
Status: Tx Pkts: 528 Line Status: Down
Collisions: 0 Rx Pkts: 505 Upstream Speed: 0 kbps
CPU Load = 2.12% Downstream Speed: 0 kbps

Press Command:
COMMANDS: 1-Reset Counters ESC-Exit

Table 120 Menu 24.1 System Maintenance: Status

FIELD

DESCRIPTION

Node-Lnk

This is the node index number and link type. Link types are: PPP, ENET, 1483.

Status

This shows the status of the remote node.

TxPkts

The number of transmitted packets to this remote node.

RxPkts

The number of received packets from this remote node.

Errors

The number of error packets on this connection.

Tx B/s

This shows the transmission rate in bytes per second.

Rx B/s

This shows the receiving rate in bytes per second.

Up Time

This is the time this channel has been connected to the current remote node.

My WAN IP

(from ISP)

This is the IP address of the ISP remote node.

Ethernet

This shows statistics for the LAN.

Status

This shows the current status of the LAN.

Tx Pkts

This is the number of transmitted packets to the LAN.

Rx Pkts

This is the number of received packets from the LAN.

Collision

This is the number of collisions.

WAN

This shows statistics for the WAN.
