Prestige 2602HW Series User’s Guide
Chapter 40 IP Policy Routing 393
Figure 246 Menu 25.1 IP Routing Policy Setup
Type a number from 1 to 6 to display Menu 25.1.1 – IP Routing Policy (see the next figure).
This menu allows you to configure a policy rule.
Menu 25.1 - IP Routing Policy Setup
# A Criteria/Action
- - --------------------------------------------------------------------------
1 Y SA=1.1.1.1-1.1.1.1,DA=2.2.2.2-2.2.2.5
SP=20-25,DP=20-25,P=6,T=NM,PR=0 |GW=192.168.1.1,T=MT,PR=0
2 N __________________________________________________________________________
__________________________________________________________________________
3 N __________________________________________________________________________
__________________________________________________________________________
4 N __________________________________________________________________________
__________________________________________________________________________
5 N __________________________________________________________________________
__________________________________________________________________________
6 N __________________________________________________________________________
__________________________________________________________________________
Enter Policy Rule Number (1-6) to Configure:
Table 130 Menu 25.1 IP Routing Policy Setup
ABBREVIATION MEANING
Criterion SA Source IP Address
SP Source Port
DA Destination IP Address
DP Destination Port
P IP layer 4 protocol number (TCP=6, UDP=17…)
T Type of service of incoming packet
PR Precedence of incoming packet
Action GW Gateway IP address
T Outgoing Type of service
P Outgoing Precedence
Service NM Normal
MD Minimum Delay
MT Maximum Throughput
MR Maximum Reliability
MC Minimum Cost
