Prestige 2602HW Series User’s Guide

Chapter 25 Menu 3 LAN Setup

281

C

H A P T E R

25

Menu 3 LAN Setup

This chapter covers how to configure your wired Local Area Network (LAN) settings.

25.1 LAN Setup

This section describes how to configure the Ethernet using Menu 3 — LAN Setup. From the
main menu, enter 3 to display menu 3.

Figure 135 Menu 3 LAN Setup

25.1.1 General Ethernet Setup

This menu allows you to specify filter set(s) that you wish to apply to the Ethernet traffic. You
seldom need to filter Ethernet traffic; however, the filter sets may be useful to block certain
packets, reduce traffic and prevent security breaches.

Figure 136 Menu 3.1 LAN Port Filter Setup

If you need to define filters, please read

Chapter 33 on page 331

first, then return to this menu

to define the filter sets.

25.2 Protocol Dependent Ethernet Setup

Depending on the protocols for your applications, you need to configure the respective
Ethernet Setup, as outlined below.

Menu 3 - LAN Setup
1. LAN Port Filter Setup
2. TCP/IP and DHCP Setup

5. Wireless LAN Setup
Enter Menu Selection Number:

Menu 3.1 - LAN Port Filter Setup
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Press ENTER to Confirm or ESC to Cancel:
