Prestige 2602HW Series User’s Guide

Chapter 25 Menu 3 LAN Setup

283

Follow the instructions in the following table to configure TCP/IP parameters for the Ethernet port.

Size of Client IP Pool

This field specifies the size or count of the IP address pool.

Primary DNS Server
Secondary DNS Server

Enter the IP addresses of the DNS servers. The DNS servers are passed to

the DHCP clients along with the IP address and the subnet mask.

Remote DHCP Serve

If Relay is selected in the DHCP field above then enter the IP address of the

actual remote DHCP server here.

Table 94 TCP/IP Ethernet Setup

FIELD

DESCRIPTION

TCP/IP Setup

IP Address

Enter the (LAN) IP address of your Prestige in dotted decimal notation

IP Subnet Mask

Your Prestige will automatically calculate the subnet mask based on the IP address

that you assign. Unless you are implementing subnetting, use the subnet mask

computed by the Prestige (refer to the appendix on IP subnetting for more

information).

RIP Direction

Press [

SPACE BAR

] to select the RIP direction. Choices are Both, In Only, Out

Only or None.

Version

Press [

SPACE BAR]

to select the RIP version. Choices are RIP-1, RIP-2B or RIP-

2M.

Multicast

IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to

establish membership in a Multicast group. The Prestige supports both IGMP

version 1 (IGMP-v1) and version 2 (IGMP-v2). Press the [

SPACE BAR]

to enable

IP Multicasting or select None to disable it.

IP Policies

Create policies using SMT menu 25 (see

Chapter 40 on page 391

) and apply them

on the Prestige LAN interface here. You can apply up to four IP Policy sets (from

twelve) by entering their numbers separated by commas.

Edit IP Alias

The Prestige supports three logical LAN interfaces via its single physical Ethernet

interface with the Prestige itself as the gateway for each LAN network. Press

[

SPACE BAR

] to change No to Yes and press [

ENTER

] to display Menu 3.2.1.

Table 93 DHCP Ethernet Setup (continued)

FIELD

DESCRIPTION
