Prestige 2602HW Series User’s Guide

Chapter 42 VPN/IPSec Setup

413

Figure 262 Menu 27.1.1.2 Manual Setup

The following table describes the fields in this menu.

Menu 27.1.1.2 – Manual Setup

Active Protocol= ESP Tunnel
ESP Setup
SPI (Decimal)= 0
Encryption Algorithm= DES
Key1= ?
Key2= N/A
Key3= N/A
Authentication Algorithm= MD5
Key= ?

AH Setup
SPI (Decimal)= N/A
Authentication Algorithm= N/A
Key= N/A

Press ENTER to Confirm or ESC to Cancel:

Table 137 Menu 27.1.1.2 Manual Setup

FIELD

DESCRIPTION

Active

Protocol

Press [SPACE BAR] to choose from ESP Tunnel, ESP Transport, AH Tunnel or AH

Transport and then press [ENTER]. Choosing an ESP combination causes the AH

Setup fields to be non-applicable (N/A)

ESP Setup

The ESP Setup fields are N/A if you chose an AH Active Protocol.

SPI (Decimal) The SPI must be unique and from one to four integers ("0" to "9").

Encryption

Algorithm

Press [SPACE BAR] to choose from NULL, DES, 3DES or AES and then press

[ENTER]. Fill in the Key1 field below when you choose DES and fill in fields Key1 to

Key3 when you choose 3DES. Select NULL to set up a tunnel without encryption.

When you select NULL, you do not enter any encryption keys.

Key1

Enter a unique eight-character key. Any character may be used, including spaces, but

trailing spaces are truncated.
Fill in the Key1 field when you choose DES and fill in fields Key1 to Key3 when you

choose 3DES.

Key2

Enter a unique eight-character key. It can be comprised of any character including

spaces (but trailing spaces are truncated).

Key3

Enter a unique eight-character key. It can be comprised of any character including

spaces (but trailing spaces are truncated).

Authentication

Algorithm

Press [SPACE BAR] to choose from MD5 or SHA1 and then press [ENTER].

Key

Enter the authentication key to be used by IPSec if applicable. The key must be

unique. Enter 16 characters for MD5 authentication and 20 characters for SHA-1

authentication. Any character may be used, including spaces, but trailing spaces are

truncated.

AH Setup

The AH Setup fields are N/A if you chose an ESP Active Protocol.

SPI (Decimal) The SPI must be from one to four unique decimal characters ("0" to "9") long.
