Prestige 2602HW Series User’s Guide

Chapter 42 VPN/IPSec Setup

407

Figure 260 Menu 27.1.1 IPSec Setup

The following table describes the fields in this menu.

Menu 27.1.1 – IPSec Setup

Index= 1 Name= Taiwan

Active= Yes Keep Alive= No Nat Traversal= No

Local ID type= IP Content:

My IP Addr= 0.0.0.0

Peer ID type= IP Content:

Secure Gateway Address= zw50test.zyxel.com.tw

Protocol= 0 DNS Server= 0.0.0.0

Local:

Addr Type= SINGLE

IP Addr Start= 1.1.1.1

End/Subnet Mask= N/A

Port Start= 0

End= N/A

Remote:

Addr Type= SUBNET

IP Addr Start= 4.4.4.4

End/Subnet Mask= 255.255.0.0

Port Start= 0

End= N/A

Enable Replay Detection = No

Key Management= IKE

Edit Key Management Setup= No


Press ENTER to Confirm or ESC to Cancel:

Table 134

Menu 27.1.1 IPSec Setup

FIELD

DESCRIPTION

Index

This is the VPN rule index number you selected in the previous menu.

Name

Enter a unique identification name for this VPN rule. The name may be up to 32

characters long but only 10 characters will be displayed in Menu 27.1 - IPSec

Summary.

Active

Press [SPACE BAR] to choose either Yes or No. Choose Yes and press [ENTER] to

activate the VPN tunnel. This field determines whether a VPN rule is applied before a

packet leaves the firewall.

Keep Alive

Press [SPACE BAR] to choose either Yes or No. Choose Yes and press [ENTER] to

have the Prestige automatically re-initiate the SA after the SA lifetime times out, even

if there is no traffic. The remote IPSec router must also have keep alive enabled in

order for this feature to work.
