Prestige 2602HW Series User’s Guide
Chapter 42 VPN/IPSec Setup
405
A
Y signifies that this VPN rule is active.
Local Addr
Start
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to Single, this is a
static IP address on the LAN behind your Prestige.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to Range, this is
the beginning (static) IP address, in a range of computers on the LAN behind your
Prestige.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to SUBNET, this
is a static IP address on the LAN behind your Prestige.
Addr End /
Mask
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to Single, this is
the same (static) IP address as in the Local Addr Start field.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to Range, this is
the end (static) IP address, in a range of computers on the LAN behind your Prestige.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to SUBNET, this
is a subnet mask on the LAN behind your Prestige.
Encap
This field displays Tunnel mode or Transport mode. See earlier for a discussion of
these. You need to finish configuring the VPN policy in menu 27.1.1.1 or 27.1.1.2 if ???
is displayed.
IPSec
Algorithm
This field displays the security protocols used for an SA. ESP provides confidentiality
and integrity of data by encrypting the data and encapsulating it into IP packets.
Encryption methods include 56-bit DES and 168-bit 3DES. NULL denotes a tunnel
without encryption.168-bit 3DES and 128-bit AES. NULL denotes a tunnel without
encryption.
AH (Authentication Header) provides strong integrity and authentication by adding
authentication information to IP packets. This authentication information is calculated
using header and payload data in the IP packet. This provides an additional level of
security. AH choices are MD5 (default - 128 bits) and SHA -1(160 bits).
Both AH and ESP increase the Prestige’s processing requirements and
communications latency (delay).
You need to finish configuring the VPN policy in menu 27.1.1.1 or 27.1.1.2 if ??? is
displayed.
Key Mgt
This field displays the SA’s type of key management, (IKE or Manual).
Remote Addr
Start
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to Single, this is a
static IP address on the network behind the remote IPSec router.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to Range, this is
the beginning (static) IP address, in a range of computers on the network behind the
remote IPSec router.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to SUBNET, this
is a static IP address on the network behind the remote IPSec router.
This field displays N/A when you configure the Secure Gateway Address field in SMT
27.1.1 to 0.0.0.0.
Addr End /
Mask
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to Single, this is
the same (static) IP address as in the Remote Addr Start field.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to Range, this is
the end (static) IP address, in a range of computers on the network behind the remote
IPSec router.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to SUBNET, this
is a subnet mask on the network behind the remote IPSec router.
This field displays N/A when you configure the Secure Gateway Address field in SMT
27.1.1 to 0.0.0.0.
Table 133 Menu 27.1 IPSec Summary (continued)
FIELD
DESCRIPTION
