Appendix D
Core Latency
Transmit Path Latency
As measured from a data octet accepted on tx_data[7:0] of the transmitter client-side
interface, until that data octet appears on gmii_txd[7:0] of the physical side GMII style
interface, the latency through the core in the transmit direction is 9 clock periods of
gtx_clk
.
Receive Path Latency
As measured from a data octet accepted on gmii_rxd[7:0] of the physical side GMII
style interface, until that data octet appears on rx_data[7:0] of the receiver client-side
interface, the latency through the core in the receive direction is 9 clock periods of
gmii_rx_clk
.
