1-Gigabit Ethernet MAC v8.5 User Guide
123
UG144 April 24, 2009
R
-- DISCONTINUED PRODUCT --
Chapter 12
Implementing Your Design
This chapter describes how to simulate and implement your design containing the
GEMAC core.
Pre-implementation Simulation
A unit delay structural model of the GEMAC core netlist is provided as a CORE
Generator™ output file. This can be used for simulation of the block in the design phase of
the project.
Using the Simulation Model
For information about setting up your simulator to use the pre-implemented model, see
the Xilinx Synthesis and Verification Design Guide, included in your Xilinx software
installation.
The unit delay structural model of the GEMAC core can be found in the CORE Generator
project directory. Details of the CORE Generator outputs can be found in the 1-Gigabit
Ethernet MAC Getting Started Guide.
VHDL
•
Verilog
•
Synthesis
XST—VHDL
A component and instantiation template for the core named
provided in the CORE Generator project directory. Use this to help instance the GEMAC
core into your VHDL source.
After your entire design is complete, create:
•
An XST project file top_level_module_name.prj listing all the user source code
files.
•
An XST script file top_level_module_name.scr containing your required
synthesis options.
