Press

Display Shows

Action/Explanation

HOST

HANDSHAKE

Setting Host Handshake

Press the right or left oval key to

display other choices.
Default: XON/XOFF

Selections: XON/XOFF, DTR/DSR

The handshake protocol of the printer must match the

handshake protocol of the host for communications to take

place. Select the handshake protocol that matches the one

being used by the host.

PROTOCOL

Setting Protocol

Press the right or left oval key to display

other choices.
Default: None

Selections: None, Zebra, ACK/NACK

Protocol is a type of error checking system. Depending on the

selection, an indicator may be sent from the printer to the host

signifying that data has been received. Select the Protocol that

is requested by the host. Further details on Protocol can be

found in the ZPL II Programming Guide, available from Zebra

Technologies Corporation.
NOTE: Zebra is the same as ACK/NACK except that with

Zebra the response messages are sequenced.
NOTE: If Zebra is selected, printer must use “DTR/DSR” host

handshake protocol.

NETWORK ID

Setting Network ID

Press the left oval key to move to the

next digit position, press the right oval key to increase the

value of the digit.
Default: 000

Range: 000 - 999

Network ID is used to assign a unique number to a printer

used in a network. This gives the host the means to address a

specific printer. If the printer is used in a network, you must

select a Network ID number.

Zebra XiII-Series User’s Guide

39
